CHD 2050

Compact cash register

The entry level, small size cash register CHD 2050 is created for small to medium size retail locations. Despite its compact size this cash register provides the same functionality as a standard cash register.

ECR parameters
PLU count 2000
PLU groups 100
Departments 8
Taxes 5
Payments 3
Currencies 5
Users 10
Graphical logo
Reports Financial, Departments, Hourly, PLU, Clerk, In-Drawer
Electronic journal
Physical parameters
Dimensions 190(W) x 215(L) x 115(H)
Weight 0.9kg
Case Plastic
Operation temp. 0ºC to +45ºC
Humidity 10% - 90%
Keyboard Stroke
Number of keys 36
Sound indicators Yes
Operator display Graphic, backlight, green
Customer display LCD, 1 x 10 numeric
RS232 Interface 1x
USB
UV detector Yes
Cash drawer port
Power supply 9V
Printer
Printer type Thermal
Printer reliability 50km
Print speed 40 mm/s (max)
Number of columns 32
Paper roll 57 mm, Ø50mm
Printer width 58mm
Paper roll change method Easy-load
Thermal paper rolls 57mmx45m
Battery
Additional battery
Battery type 2200 mAh
