CHD TH508

Thermal printer
  • Heavy duty
  • Vertical or horizontal placement on table
  • USB, Ethernet and RS232 interfaces
  • Microsoft® Windows™, MacOS, Linux and OPOS drivers available

macOS is a trademark of Apple Inc.

Physical parameters
Dimensions 130 (W) x 130 (L) x 130 (H) mm
Case plastic
Case colour dark grey
Power 24V DC 2.5A
Operating tempetature -10°C to +50°C
Operating humidity 85% max
Printer
Printer thermal direct
Print mechanism SII CAP06-347-A1
Printing method thermal line dot printing
Number of dots/line 576
Resolution 203 dpi or 8dots/mm
Speed max 250 mm/sec.
Print width 72 mm
Paper size 80mm, Ø 80 mm
Cutter full cut or partial cut
Full cutter cycle 1 500 000 cuts or more
Printer head life 150 million or more
Abrasion resistance 100 km or more
Sensors
Indicators paper end, cover open
Interface RS232, USB, Ethernet
Printer position vertical or horizontal
Cash drawer RJ11
Wall mount

Documentation
